Technical data
Nominal power (kW): 16.0
Range of heating power (kW): 7.0-20.0
Thermal efficiency (%): 81.0
Exhaust outlet diameter (mm): 200
Meets ECODESIGN criteria: Yes
Intended for recuperation: Yes
Fuel type: recommended seasoned hardwood with a moisture content of ≤20%
CO emission (at 13% O 2) ≤ given in%: 0.09
Flue gas temperature (℃): 260.0
Max log length (cm): 50
The issue of pollen (dust) (mg / Nm3): 20.0
Compliance with BImSchV 2 standard: Yes
The energy efficiency index EEI: 106.70
Glazing type: straight, tunnel
Opening the door: to the left
Material: steel
Air intake: Yes
The lining of the combustion chamber: Yes
The lining of the combustion chamber: Yes
Decorative glass type glass: Yes
Benefits
MAXIMUM USE OF ENERGY
More efficient combustion and longer temperature maintenance thanks to the lining of the combustion chamber with TERMOTEC, a heat-accumulating material that increases the temperature in the furnace.
Combustion of fuel particles thanks to two deflectors that extend the exhaust path. This process also increases the efficiency of combustion and guarantees better use of energy, and thus minimizes the emission of harmful substances into the atmosphere.
The air supply to the insert takes place only from the outside, thanks to the built-in 125 mm air inlet connection. Its regulation is done with a throttle set by one regulator located below the door, which excludes errors in improper use. The whole mechanism works very quietly and flawlessly.
The insert uses a double combustion chamber venting system. Primary air, facilitating the ignition of wood, is supplied under the grate.
Additionally, the insert uses a clean glass system (air curtain), i.e. air is supplied directly to the glass through a system of channels located on the sides of the fireplace. In this way, oxygen is supplied to the upper part of the combustion chamber, where the gases resulting from the combustion of wood are burnt, which additionally reduces the emission of harmful CO to the atmosphere.
The use of such a ventilation system enables very precise control of the combustion process.
SAFETY AT THE HIGHEST LEVEL
The front of the insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660 ° C. The glass we offer has a quality and safety certificate.
The special perforated design of the handle protects against overheating, which increases the comfort of using the fireplace.
The body and the front of the insert are resistant to high temperatures thanks to the use of high-quality steel.
Perfect tightness thanks to solid welds made in a noble gas shield. Steel elements are laser cut with the use of modern devices and then bent on CNC bending machines.
ECOLOGICAL COMBUSTION
The device meets the Ecodesign requirements and the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT USE
The fireplace has a specially profiled bottom plate made of TERMOTEC material, thanks to which the combustion chamber is deeper and contains more wood.
Removable grate and ash pan make it easier to keep the insert clean.
Limited soot deposition occurs thanks to the clean glass system used. The air curtain separates the glass from the firebox. Thanks to this, it does not get dirty and gives more heat to the room.
The possibility of leveling the unevenness of the ground and leveling the insert thanks to the adjustable feet.
The model is equipped with a movable exhaust outlet, thanks to which it is not necessary to purchase additional elbows in the case of installation. You can easily adjust the angle of connecting the insert to the chimney system.
MODERN DESIGN
The insert is equipped with two front and rear doors (instead of the back wall), thanks to which the heat radiates in two directions.
This type of fireplace is a frequently chosen solution for installation between adjacent rooms, e.g. a living room and a dining room or a bedroom.
The insert is equipped with a single, decorative glass pane, thanks to which it looks elegant and modern. The use of this solution optically enlarges the front of the insert and emphasizes the vision of fire.
LUCY 16 Tunnel
10 700,00 zł
Simple air fireplace insert
Available on backorder
Description
Please confirm availability before ordering
Technical data
Nominal power (kW): 16.0
Range of heating power (kW): 7.0-20.0
Thermal efficiency (%): 81.0
Exhaust outlet diameter (mm): 200
Meets ECODESIGN criteria: Yes
Intended for recuperation: Yes
Fuel type: recommended seasoned hardwood with a moisture content of ≤20%
CO emission (at 13% O 2) ≤ given in%: 0.09
Flue gas temperature (℃): 260.0
Max log length (cm): 50
The issue of pollen (dust) (mg / Nm3): 20.0
Compliance with BImSchV 2 standard: Yes
The energy efficiency index EEI: 106.70
Glazing type: straight, tunnel
Opening the door: to the left
Material: steel
Air intake: Yes
The lining of the combustion chamber: Yes
The lining of the combustion chamber: Yes
Decorative glass type glass: Yes
Benefits
MAXIMUM USE OF ENERGY
More efficient combustion and longer temperature maintenance thanks to the lining of the combustion chamber with TERMOTEC, a heat-accumulating material that increases the temperature in the furnace.
Combustion of fuel particles thanks to two deflectors that extend the exhaust path. This process also increases the efficiency of combustion and guarantees better use of energy, and thus minimizes the emission of harmful substances into the atmosphere.
The air supply to the insert takes place only from the outside, thanks to the built-in 125 mm air inlet connection. Its regulation is done with a throttle set by one regulator located below the door, which excludes errors in improper use. The whole mechanism works very quietly and flawlessly.
The insert uses a double combustion chamber venting system. Primary air, facilitating the ignition of wood, is supplied under the grate.
Additionally, the insert uses a clean glass system (air curtain), i.e. air is supplied directly to the glass through a system of channels located on the sides of the fireplace. In this way, oxygen is supplied to the upper part of the combustion chamber, where the gases resulting from the combustion of wood are burnt, which additionally reduces the emission of harmful CO to the atmosphere.
The use of such a ventilation system enables very precise control of the combustion process.
SAFETY AT THE HIGHEST LEVEL
The front of the insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660 ° C. The glass we offer has a quality and safety certificate.
The special perforated design of the handle protects against overheating, which increases the comfort of using the fireplace.
The body and the front of the insert are resistant to high temperatures thanks to the use of high-quality steel.
Perfect tightness thanks to solid welds made in a noble gas shield. Steel elements are laser cut with the use of modern devices and then bent on CNC bending machines.
ECOLOGICAL COMBUSTION
The device meets the Ecodesign requirements and the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT USE
The fireplace has a specially profiled bottom plate made of TERMOTEC material, thanks to which the combustion chamber is deeper and contains more wood.
Removable grate and ash pan make it easier to keep the insert clean.
Limited soot deposition occurs thanks to the clean glass system used. The air curtain separates the glass from the firebox. Thanks to this, it does not get dirty and gives more heat to the room.
The possibility of leveling the unevenness of the ground and leveling the insert thanks to the adjustable feet.
The model is equipped with a movable exhaust outlet, thanks to which it is not necessary to purchase additional elbows in the case of installation. You can easily adjust the angle of connecting the insert to the chimney system.
MODERN DESIGN
The insert is equipped with two front and rear doors (instead of the back wall), thanks to which the heat radiates in two directions.
This type of fireplace is a frequently chosen solution for installation between adjacent rooms, e.g. a living room and a dining room or a bedroom.
The insert is equipped with a single, decorative glass pane, thanks to which it looks elegant and modern. The use of this solution optically enlarges the front of the insert and emphasizes the vision of fire.
The door of the insert has a convenient handle.
