HITZE ARDENTE 17kW 90 × 41.G fireplace insert

Description

ARDENTE air-cooled fireplace insert

Security:

• Opening the furnace with the use of a new guillotine mechanism ensuring tightness of the insert, safety against opening by children and with service access.
• The design of the insert minimizes the effect of smoke being drawn back into the room when the door is opened.

Comfort:

• A wide hearth with a cast iron grate, independently aired and controlled by a throttle.
• A large ash container in the form of a removable drawer under the grate.
• Automatic maintenance of clean windows thanks to a three-sided air guide with independent air supply, ensuring the formation of an air curtain protecting the glass from contamination. Outside air is supplied through the connector Ø125,

Quality and ecology:

• The shell of the insert is made of high-grade boiler steel (P265GH according to EN 10028-2) with the use of automated production and modern CNC devices (Laser 2D, 3D, press brakes).
• The concrete deflector allows for longer combustion of fuel particles, extends the exhaust path and optimizes the combustion process by increasing the temperature inside the chamber.
• Improvement of combustion parameters and efficiency thanks to the lining of the combustion chamber with refractory ceramic panels made of ceramic concrete that accumulate heat in the combustion chamber.
• Meets BImSchV II, ECODESIGN standards.

Installation:

• The insert is equipped with a Ø200 cast iron flue with a 360 degree adjustment, which enables the discharge of exhaust gases in every direction.
• Adjusting the height and leveling the fireplace is possible thanks to the legs (you can unscrew an additional 4 cm).
• In accordance with the requirements of the Ecodesign Directive in the EU Member States: “This product cannot be used as the primary source of heating”

Energy class: A.

Ecodesign: yes

BlmSchV II: yes

Nominal power (kW): 17

Heating load range (kW): 8.5-22

Thermal efficiency (%): 79

The emission of pollen at 13% O₂ (g/m³) : 0,034

CO emission at 13% O₂ (g/m³) : 0,903

Possibility of warm building: no

Weight (kg): 363

Flue diameter (mm): 200

Inlet diameter (mm): 125

Active field of outlet grilles (cm²): 1190-1360

Active field of inlet grilles (cm²): 680-1100

Glass dimensions: 900 x 410
