The design of the insert minimizes the effect of smoke being drawn back into the room when the door is opened.
Comfort:
A wide hearth with a cast iron grate, independently aired and controlled by a throttle.
A large ash container in the form of a removable drawer under the grate.
Automatic maintenance of clean windows thanks to a three-sided air guide with independent air supply, ensuring the formation of an air curtain protecting the glass from contamination. Outside air is supplied through the connector Ø125,
Quality and ecology:
The shell of the insert is made of high-grade boiler steel (P265GH according to EN 10028-2) with the use of automated production and modern CNC devices (Laser 2D, 3D, press brakes).
The concrete deflector allows for longer combustion of fuel particles, extends the exhaust path and optimizes the combustion process by increasing the temperature inside the chamber.
Improvement of combustion parameters and efficiency thanks to the lining of the combustion chamber with refractory ceramic panels made of ceramic concrete that accumulate heat in the combustion chamber.
Meets BImSchV II, ECODESIGN standards.
Installation:
The insert is equipped with a Ø200 cast iron flue with a 360 degree adjustment, which enables the discharge of exhaust gases in every direction.
Adjusting the height and leveling the fireplace is possible thanks to the legs (you can unscrew an additional 4 cm).
In accordance with the requirements of the Ecodesign Directive in the EU Member States: “This product cannot be used as the primary source of heating”
HITZE ARDENTE 17kW 90 × 41.S fireplace insert
15 110,00 zł
Available on backorder
Description
ARDENTE air-cooled fireplace insert
Security:
Comfort:
Quality and ecology:
Installation:
Energy class: A.
Ecodesign: yes
BlmSchV II: yes
Nominal power (kW): 17
Heating load range (kW): 8.5-22
Thermal efficiency (%): 79
The emission of pollen at 13% O2 (g/m³) : 0,034
CO emission at 13% O2 (g/m³) : 0,903
Possibility of warm building: no
Weight (kg): 363
Flue diameter (mm): 200
Inlet diameter (mm): 125
Active field of outlet grilles (cm²): 1190-1360
Active field of inlet grilles (cm²): 680-1100
Glass dimensions: 900 x 410
Additional information
wood
HITZE
air
straight glass
